This Vermeer D24x40 Series III Horizontal Directional Drill (PIN: 1VRX200FCS1003807) is a 2025 model year machine manufactured in December 2024, built for heavy-duty underground utility installation, pipe laying, and conduit placement. Powered by a 93 kW (125 HP) John Deere 4.5L Tier 4 Final / Stage V diesel engine, the machine has an approximate mass of 10,100 kg (22,266 lbs) and operates on a high-traction rubber track undercarriage. Known for its strong drilling capabilities in compact jobsites, the D24x40 III delivers high rotational torque, reliable thrust/pullback performance, an integrated hydraulic vise/breakout system, and a semi-automated rod loader setup to maximize daily linear footage productivity on utility installation projects.

Based on the recent trade-in inspection report at 826 operating hours, the drill shows good overall functional capability but requires several notable maintenance services and mechanical repairs. Overall sheet metal, track tension, and engine operation pass inspection, but a full 250-hour service is currently due (including low engine oil caused by leaking front cover and oil seals). Additionally, the rear rotation/thrust gearbox seal and fan drive motor are actively leaking oil, and the carriage slides along with the rod loader arm slides are worn down and breaking apart. Electrically and controls-wise, the remote control will not power on despite a full battery charge, the main joystick boot is torn (exposing internal wiring to moisture), and a rod loader arm safety guard is missing with the arm slightly misaligned.

‍
